HANTENCNC’s portable handheld laser cleaning machine uses a high-energy density laser beam, which can quickly remove rust, oxide layer, paint and other dirt from the surface of materials, saving energy and environmental protection.
Our portable handheld laser cleaning machine is equipped with a laser cleaning gun and a retractable screen, 700W-2000W exclusive customization according to your needs, achieving efficient cleaning.
Why did you choose us?
1.Portable: Mini style portable laser cleaning machine, lightweight, mobile.
2.Easy to Use: The operation interface is simple, and beginners can get started quickly.
3.Multiple Modes: Portable laser cleaning machine supports 6 cleaning modes and 24 languages to meet different needs.
4.Good Cleaning Effect: Laser cleaning technology can quickly decompose dirt and improve cleaning efficiency.
5.Hight Precision: Accurately control the position and intensity of the laser beam.
6.Technical Service: Factory technical engineers directly connect with services to efficiently solve problems.
Portable Handheld Laser Cleaning Machine Video
Portable Handheld Laser Cleaning Machine Display
Details Display of Portable Handheld Laser Cleaning Machine
HANTENCNC’s handheld laser cleaning machine is equipped with an oil-water separator, sponge handle, touch control screen, laser cleaning gun, emergency stop knob, and movable wheels.
Portable Handheld Laser Cleaning Machine Dimensions
The Function of Portable Handheld Laser Cleaning Machine
Lightweight and Flexible Design
The cabinet of the portable handheld laser cleaning machine is equipped with wheels, making it easy to move within the work area, saving workspace, and improving work efficiency.
The portable laser cleaning machine is compact and lightweight, equipped with a touch screen and emergency pause knob, which facilitates data recording and analysis, and ensures the safety of the laser cleaning process, improving user comfort.
Laser Cleaning Gun
The laser cleaning gun design of the portable laser cleaning machine is ergonomic, comfortable to grip, lightweight, and easy to grip.
Our laser cleaning head has the characteristics of high efficiency, non-destructive, and pollution-free; Intelligent systems, mobile applications, and PC monitoring provide real-time feedback on work status.
The laser cleaning gun has strong controllability, achieving selective cleaning of precise positions and sizes, saving time and labor costs.
Oil Water Separator
The oil-water separator can effectively prevent dust and smoke from entering, reduce lens contamination, and extend the service life of protective lenses. Clean lenses can maintain the focusing performance of the laser beam, thereby improving cleaning efficiency.
The oil-water separator can protect internal machinery, reduce corrosion and wear on laser cleaning machines, improve operational efficiency, and reduce maintenance costs.
Air-Cooled
The air-cooled laser cleaning machine uses fans and air flow devices to dissipate heat, with low installation and maintenance costs, energy conservation and environmental protection, strong adaptability, and flexible use in various environments.
Compared to water-cooled devices, air-cooled devices usually have lower operating costs, a simple and intuitive structure, and reduced maintenance frequency.
Well-organized Internal Wiring
Through clear circuit layout, problems can be quickly located, maintenance costs of portable laser cleaning machine can be reduced, erroneous operations can be reduced, and safety can be improved.
6 Cleaning mode for Portable Handheld Laser Cleaning Machine
Single pendulum mode and double pendulum mode support customization, while double pendulum mode supports 6 cleaning modes, namely:
1.Straight Line
2.Vertical Line
3.Ellipse
4.Rotate Fill Circle
5.Straight Filled Rectangle
6.Line Filled Circle
24 Languages for Portable Handheld Laser Cleaning Machine
The portable laser cleaning machine provides customized language services to better meet the technical needs of users, supporting 24 languages, and you can choose the desired language.
HANTENCNC’s laser cleaning machine currently supports：
Chinese, Traditional, English, Türkiye, Russian, German, Czech, French, Thai, Arabic, Portuguese, Spanish, Korean, Japanese, Polish, Italian, Hungarian, Vietnamese, Greek, Ukrainian, Finnish, Norwegian, Croatian, Slovenian.
Display of Cleaning Results
Portable Handheld Laser Cleaning Machine Parameters
| Model | HTCL700 | HTCL1200 | HTCL1500 | HTCL2000 |
| Laser Power | 700W | 1200W | 1500W | 2000W |
| Laser Source | Rlaser | Rlaser | Everfoton/Rlaser | Rlaser |
| Operating Mode | Continuous Cleaning | Continuous Cleaning | Continuous Cleaning | Continuous Cleaning |
| Refrigeration System | Air-cooled | Air-cooled | Air-cooled | Air-cooled |
| Operational Voltage | 220V/2P | 220V/2P | 220V/2P | 380V/3P |
| Dimension | 640mm*608.5mm*346.2mm | 640mm*608.5mm*346.2mm | 640mm*608.5mm*346.2mm | 640mm*608.5mm*346.2mm |
| Weight | About 52.8Kg | About 52.8Kg | About 53Kg | About 58Kg |
LASER CLEANING GUN PARAMETERS |
||||
| Fiber Optic Interface | QBH | QBH | QBH | QBH |
| Wavelength Range | 1070±20nm | 1070±20nm | 1070±20nm | 1070±20nm |
| Rated Power | ≤3000W | ≤3000W | ≤3000W | ≤3000W |
| Intelligent Protection Function | Yes | Yes | Yes | Yes |
| Collimating Focal Length | 50mm | 50mm | 50mm | 50mm |
| Focusing Focal Length | 800mm | 800mm | 800mm | 800mm |
| Scanning Range | 10-300mm | 10-300mm | 10-300mm | 10-300mm |
| Maximum Scanning Speed | 20000mm/s | 20000mm/s | 20000mm/s | 20000mm/s |
| Auxiliary Air Pressure | ≥0.5～0.8Mpa | ≥0.5～0.8Mpa | ≥0.5～0.8Mpa | ≥0.5～0.8Mpa |
| Effective Aperture | 23mm | 23mm | 23mm | 23mm |
| Weight | 0.78KG | 0.78KG | 0.78KG | 0.78KG |
