HANTENCNC’s 1500W, 2000W, and 3000W laser cleaning machines are compact and lightweight, saving both shipping costs and space. The continuous laser ensures zero damage to materials. More heat dissipation holes guarantee high power and prolonged usage without affecting performance stability.
HANTENCNC’s handheld laser cleaning machine meets various efficient and precise cleaning needs. Our 1500W, 2000W, and 3000W laser cleaning machines swiftly and thoroughly remove surface contaminants while maintaining material integrity, ensuring damage-free surface quality.
Whether for industrial cleaning, surface preparation, or other cleaning applications, HANTENCNC’s handheld laser cleaning machines are efficient and reliable choices.
1500W to 3000W Laser Cleaning Machines Demonstration Video
Continuous 1500W to 3000W Laser Cleaning Machines Display
1500W to 3000W Handheld Laser Cleaning Machines Dimensions
Details of 1500W 2000W 3000W Laser Cleaning Machines
Retractable Touchscreen
HANTENCNC’s 1500W 2000W 3000W handheld laser cleaning machine features a protective retractable touchscreen, ensuring durability and reliable performance.
The retractable touchscreen can be safely retracted within the laser cleaning machine, which can protect the touchscreen from external environmental impacts and damage and extend its lifespan.
Compact and Portable Design
HANTENCNC’s 1500W to 3000W continuous handheld laser cleaning machine, with its compact size and portable design, is suitable for various cleaning tasks.
Water-Cooling System
Ensures the stability of the high-power handheld laser cleaning machine.
User-Friendly Operation:
Designed control handles and buttons for effortless usage.
Continuous Laser Cleaning Gun Display
6 Cleaning Modes for Handheld Laser Cleaning Machine
You can choose the appropriate cleaning mode according to the specific cleaning task. The portable handheld laser cleaning machine supports 6 modes and can be switched freely to achieve precise and efficient cleaning results.
The six cleaning modes are:
1.Straight Line
2.Vertical Line
3.Ellipse
4.Rotate Fill Circle
5.Straight Filled Rectangle
6.Line Filled Circle
24 Languages for Handheld Laser Cleaning Machine
HANTENCNC’s laser cleaning machine currently supports：
Chinese, Traditional, English, Türkiye, Russian, German, Czech, French, Thai, Arabic, Portuguese, Spanish, Korean, Japanese, Polish, Italian, Hungarian, Vietnamese, Greek, Ukrainian, Finnish, Norwegian, Croatian, Slovenian 24 languages and you can choose the desired language.
Advantages of Handheld Continuous Cleaning Machines
High Laser Power:
The new continuous laser cleaning machine may be equipped with a high-power laser source, providing enhanced cleaning capabilities.
Energy Efficiency and Environmental Friendliness:
The design prioritizes energy efficiency, incorporating eco-friendly laser cleaning technology to reduce energy consumption and minimize environmental impact.
Versatile Applications:
In addition to cleaning, it may also support various applications such as cutting, removing oxide layers, coatings, etc., making it a multifunctional device.
1500W to 3000W Laser Cleaning Machines Effects: Before vs. After
Continuous 1500W to 3000W Laser Cleaning Machines Parameters
| MODEL | HTCL1500 | HTCL2000 | HTCL3000 |
| Laser Power | 1500W | 2000W | 3000W |
| Output Fber Core Diameter | 20μm、25μm or 50μm | 20μm、25μm or 50μm | 20μm、25μm or 50μm |
| Length of Laser Fiber Cable | 12m or Customized | 12m or Customized | 12m or Customized |
| Power Stability | ＜1.5% (2h) | ＜1.5% (2h) | ＜1.5% (2h) |
| Max Modulation Frequency | 5kHz | 5kHz | 5kHz |
| Operating Mode | Continuous Cleaning | Continuous Cleaning | Continuous Cleaning |
| Refrigeration System | Water Cooling | Water Cooling | Water Cooling |
| Cleaning Gap Requirements | ≤0.5mm | ≤0.5mm | ≤0.5mm |
| Power Adjustment Scope | 10%-100% | 10%-100% | 10%-100% |
| Operating System | Handheld Cleaning System | Handheld Cleaning System | Handheld Cleaning System |
| Operating Mode | Continuous or Modulated | Continuous or Modulated | Continuous or Modulated |
| Working Voltage | 220V | 220V | 380V |
| Optimal Working Environment Temperature | 15-35℃ | 15-35℃ | 15-35℃ |
| Humidity Range Operating Environment | < 70% Non-condensing | < 70% Non-condensing | < 70% Non-condensing |
| Dimension | 997.44mm*549.42mm*931mm | 997.44mm*549.42mm*931mm | 997.44mm*549.42mm*931mm |
| Weight | About 170KG | About 170KG | About 170KG |
LASER CLEANING GUN PARAMETERS |
|||
| Brand | Relfar | Relfar | Relfar |
| Optical Interface | QBH | QBH | QBH |
| Laser Wavelength | 1070nm±20nm | 1070nm±20nm | 1070nm±20nm |
| Power | ≤3000W | ≤3000W | ≤3000W |
| Collimating Focal Length | 50mm | 50mm | 50mm |
| Focusing Focal Length | 800mm | 800mm | 800mm |
| Scanning Width | Length 300mm * Width 300mm | Length 300mm * Width 300mm | Length 300mm * Width 300mm |
| Scanning Speed | 10-20000mm/s | 10-20000mm/s | 10-20000mm/s |
| Auxiliary Air Pressure | 20.5-0.8Mpa | 20.5-0.8Mpa | 20.5-0.8Mpa |
| Same Optical Aperture | Ø22 | Ø22 | Ø22 |
| Weight | 0.96KG | 0.96KG | 0.96KG |
