Fiber laser marking machines are compact, lightweight, and offer flexible movement without producing chemical pollution or harmful substances during the marking process. They are widely used in applications such as automotive manufacturing, electronic products, medical devices, aerospace, etc.
Advantages of fiber laser marking machine for metal engraving
1. High precision: Our laser marking machine utilizes advanced positioning technology to achieve accurate marking and ensure the consistency marking pattern.
2. High speed: Our laser marking machine adopts advanced laser technology and a high-speed scanning system, which can achieve fast and efficient marking, ensuring production progress and efficiency.
3. No consumables: Non-contact marking, no consumables, energy-saving and environmentally friendly.
4. Low cost: The laser marking machine features an energy-saving design and efficient laser technology, offering a reasonably price and highly cost-effectiveness.
Fiber Laser Marking Machine Demonstration Video
Fiber Laser Marking Machine Display
Component Details Display of Fiber Laser Marking Machine
Dimensions of Fiber Laser Marking Machine
Fiber Laser Marking Machine Parameters
MACHINE PARAMETERS |
|||
| Model | HTF-20 | HTF-30 | HTF-50 |
| Power | 20W | 30W | 50W |
| Supply voltage | 110V/220V、50/60Hz | 110V/220V、50/60Hz | 110V/220V、50/60Hz |
| Net weight | About 100Kg | About 100Kg | About 100Kg |
| Machine size | 940*970*1600mm | 940*970*1600mm | 940*970*1600mm |
OPTICAL PARAMETERS |
|||
| Laser source | JPT/Rsycus/MAX | JPT/Rsycus/MAX | JPT/Rsycus/MAX |
|
Beam quality |
＜1.5m² | ＜1.5m² | ＜1.8m² |
| Cable length | 2m | 2m | 3m |
| Maximum pulse energy | 0.8mJ | 0.8mJ | 1.25mJ |
| Frequency range | 1-600kHz | 1-600kHz | 1-600kHz |
| Marking area | 100*100mm-300*300 | 100*100mm-300*300 | 100*100mm-300*300 |
| Cooling system | Air cooled | Air cooled | Air cooled |
| Power consumption | ＜110W | ＜150W | ＜220W |
| Output beam diameter | 7±0.5mm | 7±0.5mm | 7±0.5mm |
| Laser wavelength | 1064nm | 1064nm | 1064nm |
| Marking speed | 0-7000mm/s | 0-7000mm/s | 0-7000mm/s |
| Marking Linewidth | 0.01mm-0.1mm | 0.01mm-0.1mm | 0.01mm-0.1mm |
Fiber Laser Marking Machine Details
Desktop Semi Sealed
There is a small window in front of this laser marking machine, through which we can observe the marking process.
Desktop integrated, with enough space for machines, no need for additional tables, optional desktop computer, simple and convenient operation.
We also added a protective device to provide protection. When the machine is not working, the door can be opened, and when it is working, the door can be closed.
Galvanometer System
The Galvanometer system has stability and reliability, enabling fast and accurate marking, and ensuring the certainty and consistency of markings.
It can be used for marking various materials, including metals, plastics, glass, etc, with low energy consumption, can maintain low-temperature operation during operation, reduce energy consumption and heat emissions, and extend service life.
Air Cooled System
The air-cooled system is suitable for various environmental temperature and humidity conditions and is not affected by factors such as water quality and temperature, which helps to improve equipment stability.
The air-cooled system can quickly remove heat without a complex waterway system, reducing the complexity of installation and maintenance, and reducing maintenance and labour costs.
Well-organized Internal Wiring
A clear internal wiring layout can reduce line crossing and interference, reduce troubleshooting time and costs during maintenance, improve product quality, and is an important factor in ensuring the normal operation of the laser marking machine.
