100W/200W Air-Cooled Backpack Pulse Laser Cleaner with a Removable Lithium Battery

This 100W/200W rust-stripping laser cleaner employs JPT’s laser source, which is stable, highly efficient, and cost-effective.

Our pulsed laser cleaner uses short laser pulses to evaporate surface contaminants or coatings without causing thermal or mechanical damage to the substrate. It is suitable for cleaning sensitive materials and precision components without causing damage.

HANTENCNC’s backpack laser cleaner can be applied in various industries, including industrial cleaning, cultural heritage preservation, car maintenance, and paint removal.

HANTENCNC’s laser cleaner features a backpack-type design and a removable lithium battery. Along with a portable laser cleaning gun, an independent wrist control screen, and a weight of 13.47 kg, it is perfect for mobile work in outdoor or hard-to-reach locations without a power supply.

The removable battery design makes the laser rust cleaner easier to maintain. When the battery fails or needs to be replaced, the operator can replace the battery directly without waiting for professional repair.

The removable battery design also ensures the laser cleaner is easy to carry and move.

Handheld Design

The laser rust removal gun is lightweight and portable. It only weighs 0.75 kg, making sure that users will stay energized with long-time work.

Our laser cleaning gun is equipped with professional high-performance laser lenses, fast scanning speed, and high precision to meet the needs of various laser cleaning applications.

Safety Lock

HANTENCNC’s pulse laser cleaning head is equipped with a safety lock to prevent accidental operation effectively.

The laser will only emit when the safety lock button is pressed. If the button is not pressed, the laser cannot be triggered, ensuring operator safety.

Our laser rust cleaner features a wireless control screen that can be conveniently strapped to the wrist. Users can control laser rust cleaners without being confined to a fixed location. This design enhances flexibility in operation and boosts productivity.

The portable laser cleaner by HANTENCN provides users with a selection of 9 cleaning modes on its operation interface:

1. Straight Line Mode
2. Rectangular Mode 1
3. Rectangular Mode 2
4. Circular Mode
5. Sinusoidal Mode
6. Spiral Mode
7. Free Mode
8. Ring Mode
9. Rotation Mode

To switch between these modes, select the “Scanning Mode” option on the interface.

Some cleaning modes cater to delicate surfaces, effectively addressing higher surface requirements by minimizing or completely removing traces post-cleaning. Some cleaning modes are more powerful and ideal for removing stubborn dirt or coatings.

Choosing the proper cleaning modes ensures minimal traces and enhances the appearance and quality of the product. Proper cleaning modes are particularly critical in sectors such as automotive manufacturing, aerospace, electronics, and other related industries.

HANTENCNC’s backpack pulse laser rust cleaner currently supports Chinese, Traditional Chinese, English, Russian, Spanish, Japanese, German, Korean, French, Polish and 16 other languages.

You can easily switch between these language options directly on the machine’s interface. Additionally, if you need other languages, we offer personalized language services to accommodate your needs.

Model	HTCM100	HTCM200
Operating Environment
Supply voltage	Single Phase 110V/220V± 10%, 50/60Hz AC Optional Battery, 100W Continuous Operation for 80-90 Minutes	Single Phase 110V/220V± 10%, 50/60Hz AC Optional Additional Battery, 100W Continuous Operation for 80-90 Minutes
Overall Power Consumption	<600W	≤800W
Operation Temperature	5℃~40℃	5℃~40℃
Operation Humidity	≤80%	≤80%
Optical parameters
Average Laser Power	≥100W	≥200W
Power Instability	<5%	<5%
Laser Operation Mode	Pulse	Pulse
Pulse Width	150-190ns	13-500ns
Maximum Single Pulse Energy	1.5mJ	2mJ / 5mJ
Power Adjustment Range(%)	10-100(Gradient Adjustable)	10-100(Gradient Adjustable)
Repetition Rate(kHz)	20-200(Gradient Adjustable)	20-200(Gradient Adjustable)
Fiber Cable Length	1.5m	1.5m
Center Wavelength	1064nm	1064nm
Cooling Method	Air-cooled	Air-cooled
Laser Rust Removal Gun Parameters
Laser Cleaning Gun Weight	<0.75Kg	<0.75Kg
Scanning Width	0mm-100mm	0mm-100mm
Scanning Frequency	Not Less Than 300Hz	Not Less Than 300Hz
Maximum Scanning Speed	20000mm/s	20000mm/s
Field Lens Focal Length(mm)	160mm (210mm/254mm/330mm/420mm Optional)	210mm (160mm/254mm/330mm/420mm Optional)
Machine Parameters
Machine Dimensions	213 mm*123 mm*339 mm (Without Battery) 213 mm*168 mm*339 mm (With Battery)	268 mm*135 mm*445 mm（Without Battery） 268 mm*192 mm*445 mm(With Battery)
Package Dimensions	600 mm*400 mm*360 mm	910 mm*890 mm*420 mm
Machine Weight	8.5 kg (Without Battery) 12 kg (With Battery)	13 kg (Without Battery) 18.5 kg (With Battery)
Package Weight	15.5 kg (Without Battery) 19 kg (With Battery)	50 kg (Without Battery) 55 kg (With Battery)
Laser Cleaning Gun Weight	<0.75Kg	<0.75Kg
Operation Mode	Wireless Control Screen	Wireless Control Screen

HANTENCNC’s laser cleaning machines are CE and FDA-certified. We offer a 2-year warranty for the laser source and a 1-year warranty for the entire machine.

Additionally, we provide sample testing, OEM customization, remote guidance, and lifelong after-sales support to ensure the best customer experience.
